FRAME
All New Series 3 6061 Aluminum, 29” Wheels, 130mm Travel, MultiTrac Suspension Platform, 141 Boost Spacing (upgradable to 148x12), 73mm Threaded BB w/ ISCG05 Tabs
FORK
X-Fusion Slide Boost RC, 29", 140mm Travel, Compression and Rebound Adjustment, 44mm Offset
SHOCK
X-Fusion O2 Pro R, Custom Tune, 210x55mm, M8x25mm Hardware Top and Bottom
RIMS
Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
HUB REAR
Forged Alloy, 141QR, Disc, 32H, HG Freehub Body
HUB FRONT
Forged Alloy, 110x15mm, Disc, 32H
SPOKES
14g Black Stainless Steel
TIRES
Vee Tire Co. Crown Gem 29x2.35", Dual Control Compound, Tubeless Ready
DERAILLEUR REAR
Shimano Deore, 11-Speed, SGS
DERAILLEUR FRONT
-
SHIFT LEVER
Shimano Deore, 11-Speed, SL-5100R
CRANKSET
Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, Boost Spacing
BOTTOM BRACKET
External Sealed Cartridge Bearing
CHAIN
KMC X-11 Silver and Black
CASSETTE
Sunrace, 11-Speed, 11-51T, ED Black
BRAKES FRONT
Tektro HDM-280 Hydraulic Disc, 180mm Rotor
BRAKES REAR
Tektro HDM-280 Hydraulic Disc, 180mm Rotor
BRAKE LEVERS
Tektro HDM-280
HANDLEBAR
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
STEM
Marin 3D Forged Alloy, 35mm
GRIPS
Marin MTN, Closed End
HEADSET
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
SEATPOST
Marin Alloy, 30.9mm
SADDLE
Marin Speed Concept
Closed 9-12 Thru-Axle QR System
