FRAME
Unidirectional Carbon Fiber Front Triangle, Series 4 Alloy Rear End, 29” Wheels, 125mm Travel, MultiTrac Suspension Platform, 148x12mm Boost Thru-Axle, 73mm Threaded BB w/ ISCG05 Tabs
FRONT SUSPENSION
Marzocchi Bomber Z2 29", Rail Damper with Sweep Adjustment, 130mm Travel, Kabolt Bolt-On Axle, 44mm Offset
REAR SUSPENSION
Fox Float DPS, Performance Series, EVOL Air Spring, 3 Position Compression Adjustment, Rebound Adjustment, Custom Tune, 210x50mm, M8x30mm Top, M8x25mm Bottom
RIMS
Marin Aluminum Double Wall, 29mm Inner, Sleeved Joint, Disc Specific, Tubeless Compatible
HUB, REAR
Forged Alloy, 148x12mm, Quad Sealed Bearings, Disc, 32H, Standard Freehub Body
HUB, FRONT
Forged Alloy, 110x15mm, Disc, 32H
SPOKE, NIPPLES
14g Black Stainless Steel
TIRES
Front: Maxxis Assegai 29x2.5”, 3C MaxxTerra, EXO, Tubeless Compatible
Rear: Maxxis Aggressor 29x2.5”, 3C Maxx Terra, EXO, Tubeless Compatible
DERAILLEUR, REAR
Shimano SLX, 12-Speed, SGS
DERAILLEUR, FRONT
SHIFT LEVER
Shimano SLX, 12-Speed, SL-7100R
CRANKSET
New FSA GRID, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Mego EXO Spindle, Boost Spacing
BOTTOM BRACKET
Mego EXO 73mm BSA
CHAIN
KMC X-12 Silver and Black
CASSETTE
SunRace, 12-Speed, 11-51T, ED Black
BRAKE, FRONT
Shimano MT420, 4-Piston Hydraulic Disc Brake, 203mm Rotor
BRAKE, REAR
Shimano MT420, 4-Piston Hydraulic Disc Brake, 180mm Rotor
BRAKE LEVERS
Shimano MT401 Hydraulic Lever
HANDLEBAR
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
STEM
Marin 3D Forged Alloy, 35mm
GRIPS
Marin Grizzly Single Clamp Locking
HEADSET
FSA No 42/47, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
SEATPOST
TranzX, YSP23JL, 1x Remote, Size S 125mm Travel, Size M and L 150mm Travel, Size XL 170mm Travel, 30.9mm
SADDLE
Marin Speed Concept
PEDALS
Bolt-On Thru-Axle
